MiTR School Bus
Starts At
Know Your Vehicle
Engine
Engine:
ZD30 DDTi Common Rail Diesel Engine
Power: 103 kW (140 hp)
Torque: 360 Nm
Power: 103 kW (140 hp)
Torque: 360 Nm
Clutch
310 mm Diameter
Steering
Power Steering
Weight
6650kg
Exterior Gallery
Technical specifications
MiTR School Bus – Variant Comparison
| Specification | MiTR School Bus Wheelbase 4270 mm ₹ 24.14 L |
MiTR School Bus Wheelbase 3700 mm ₹ 22.32 L |
|---|---|---|
| ENGINE | ||
| Engine | ZD30 DDTi Common Rail Diesel Engine | ZD30 DDTi Common Rail Diesel Engine |
| Fuel Type | Diesel | Diesel |
| Max Power | 103 kW (140 hp) @ 2750 rpm | 103 kW (140 hp) @ 2750 rpm |
| Max Torque | 360 Nm @ 1350–2750 rpm | 360 Nm @ 1350–2750 rpm |
| SEATING CONFIGURATIONS | — | |
| 2 × 2 (Wide Body) | — |
22 + A + D (HB, SD) 26 + A + D (STD, SD) 24 + A + D (STD, DD) |
| 3 × 3 (Wide Body) | — |
39 + A + D (STD, SD) 36 + A + D (STD, DD) |
| 3 × 2 (Wide Body) | — |
33 + A + D (STD, SD) 31 + A + D (STD, DD) |
| DIMENSIONS | ||
| Wheelbase | 4270 mm | 3700 mm |
| Overall Length | 7060 mm | 7060 mm |
| Overall Width | 2200 mm | 2200 mm |
| Overall Height | 2630 mm | 2630 mm |
| Wide Body Dimensions (L × W × H) |
7970 × 2200 × 2630 mm (Non-AC) 7970 × 2200 × 2850 mm (AC) |
7060 × 2200 × 2630 mm (Non-AC) 7060 × 2200 × 2850 mm (AC) |
| Minimum Turning Radius | 8.3 m | 7.2 m |
| Minimum Ground Clearance | 210 mm | 198 mm |
| Passenger Platform Height | 1000 mm | — |
| SUSPENSION | ||
| Front Suspension | Parabolic Suspension with Double Acting Shock Absorbers | Parabolic Suspension with Double Acting Shock Absorbers |
| Rear Suspension | Parabolic Suspension with Double Acting Shock Absorbers | Parabolic Suspension with Double Acting Shock Absorbers |
| STEERING | ||
| Steering Type | Power Steering | Power Steering |
| CLUTCH | ||
| Clutch Type | 310 mm Diameter | 310 mm Diameter |
